Description

THIS FILE NOT FOR VIP OR PLATINUM MEMBERS. PLEASE CONTACT US FOR PRICE.

Experience the power of a software bus analyzer capturing I/O, low level protocol and send commands to devices.

Bus Support
USB 1.0 - 4.0
NVMe
SATA & IDE
SCSI & ATAPI
FireWire, 1394A/B
Bluetooth
Fibre Channel
iSCSI, SAS
PC Card, PCMCIA
serial port
parallel port
ps/2 ports
...and more

OS Support
Windows 11
Windows 10
Server 2022
Server 2019

+ Windows versions back to Win95 and NT4 available to full version customers

Device Support
Blu-ray, DVD, CD
Hard drives, tape drives
Memory cards
Web Cams, Cameras
Mice, Keyboards, HID
Printers, Scanners
Speakers, Modems
...and everything else!

Power User Features
• Capture megabytes of I/O at a time
• View I/O on screen in real time
• Trigger on conditions
• Build and submit custom commands
• Issue bus and device resets
• Capture the system startup process
• View low level protocol including SCSI sense data and SMART commands
• View microsecond resolution timing
• Drag and drop captured data to other applications or save it to a zip file
• Capture isochronous and control transfers
• View IRPs and other device driver packets

Ideal Uses
• Inspect low level I/O
• Debug device drivers or firmware
• Reverse engineer protocol
• Acquire performance measurements
• Research the principles of device operation
• Uncover hard to find device properties

Bus Hound 8.0

Bus Hound is a powerful software bus analyzer for capturing I/O and protocol from devices. Features:

● Supported buses: USB, NVMe, SATA, IDE, SCSI, Bluetooth, FireWire, serial ports, parallel ports, and ps/2 ports.
● Supported devices types: disk drives, DVD, scanners, cameras, HID, and everything else
● Supports Windows 10 and later or Server 2019 and later on either x64 or arm64 processors
● Capture gigabytes of protocol at a time
● Automatically stop the capture upon a trigger condition
● Measure individual read, write, and isochronous device performance
● Captures device driver packets such as IRPs
● Filter what type of protocol is captured
● Run on an unlimited number of machines at the same time
● Capture any number of devices in parallel, regardless of bus type
● Compact install with no prerequisites and installs no redistributables
● Drag and drop captured data to other products in html format
● Save captured data to a text file or zip file
● Simple device selection from a graphical tree of devices
● Capture the system startup process
● Customize captured protocol such as the byte width per line, column order, and column types of interest
● View low level protocol including SCSI sense data and USB setup packets
● View microsecond resolution protocol timing
● Watch I/O on screen in real time as it happens
● Pure software solution--no extra hardware or system changes needed

Additional Information
